ALUMINIUM O2 GIVING SET 50L/200BAR, 2-OUTLET

(WITH 2-OUTLET PIN-INDEX REGULATOR TO SUPPLY OXYGEN TO 2 PATIENTS AT THE SAME TIME)(COMPRESSED GAS) (DG CARGO)


50 LITERS OXYGEN GIVING SET

User Manual and Instructions for Use





































50 Liters oxygen giving set – assembled view





Important Safety Notice



This manual  is intended to support safe setup and use of the oxygen giving set by trained personnel. Oxygen therapy  must be administered according to the vessel medical procedures, applicable flag requirements, and     medical/telemedical advice. In  an  emergency,  seek  medical assistance   immediately.



Contents

Product description Components and technical data Safety precautions

Set-up instructions

Humidifier instructions for use Operating instructions

Oxygen administration guidance Contents of the set and dimensions





pg. 1

1.    Product Description



The 50 liters oxygen giving set is supplied for emergency oxygen administration onboard vessels and other  appoved maritime applications. The set includes a 50 liters medical cylinder, trolley, oxygen masks,    humidifier, oxygen tubing, and sterile water as   applicable.



A 50 liters, 200 bar oxygen cylinder contains approximately 10,000 gaseous liters of medical oxygen. Actual  use duration depends  on  the cylinder  pressure  and the  selected oxygen flow   rate.



Use Restrication

This equipment shoud be used only by trained personnel and in accordance  with  the medica guide, applicable  flag  requirements,  and  medical/telemedical instructions.





2.    Main Components













F



D

A

E



B                                                                                                                               E



C























Ref

Description

A

Cylinder  valve  – on/off

B

Oxygen tubing Outlet

C

Oxygen tubing

D

Manometer / pressure gauge

E

Flow indicator / flow setting   window

F

Simple oxygen mask

G

Humidifier bottle





pg. 2

3.    Technical Data





Item

Specification

Cylinder capacity

50 liters

Cylinder pressure

200 bar

Approximate gassous oxygen content

10,000 liters

Flow range

0 to 15 LPM

Flow settings

0.5,1,2,3,4,5,6,8,10,12 and 15 LPM

Connetion

CGA 870 pin-index conneciton
