HAINING, Self-righting Inflatable liferaft, HNF-SR model
- The inflatable liferaft is stowed in the liferaft container on the deck. When pulling the painter line, The liferaft is inflated in the sea.
- Specification: 6、10、15、20、25、50、65、100 and 125 person
- Approval: CCS
| Approval standard |
| 1． MSC.81（70）Revised Recommendation on Testing of Life-saving Appliances |
| 2． MSC.48（66）International Life-saving Appliance Code |
| 3． MSC.218（82）Amendment to the International Life-saving Appliance Code(LSA Code) |
| 4． MSC.226（82）Amendment to the Revised Recommendation on Testing of Life-saving Appliances |
| 5． 1996 Amendment to the International Convention for the Safety of Life at Sea, 1974 |
| 6． MSC.293（87） and MSC.295（87） related requirement |
7． Drawing approved by CCS
|
I/C Code
|
ITEM
|
Part
|
UOM
|
|
Number
|
|
RAFT-HN1-ZZZ -
|
HAINING, 65 MEN,
SELF-RIGHTING TYPE, SOLAS A PACK,
EC-MED APPROVED
|
HNF-SR65
|
UNIT
|
|
|
Model
|
Capacity
(person)
|
Maximum Stowage height
(m)
|
SOLAS A PACK
|
SOLAS B PACK
|
|
Weight
(kg)
|
Dimension of container
(mm)
|
Weight
(kg)
|
Dimension of container
(mm)
|
|
HNF-SR6
|
6
|
36
|
90
|
Φ600×1200
|
72
|
Φ580×1100
|
|
HNF-SR10
|
10
|
118
|
Φ660×1300
|
92
|
Φ620×1200
|
|
HNF-SR15
|
15
|
156
|
Φ700×1400
|
118
|
Φ660×1300
|
|
HNF-SR20
|
20
|
200
|
Φ750×1460
|
150
|
Φ680×1400
|
|
HNF-SR25
|
25
|
230
|
Φ780×1480
|
163
|
Φ700×1400
|
|
HNF-SR50
|
50
|
392
|
Φ850×1800
|
275
|
Φ780×1800
|
|
HNF-SR65
|
65
|
500
|
Φ950×1900
|
352
|
Φ850×1800
|
|
HNF-SR100
|
100
|
820
|
Φ1100×2200
|
615
|
Φ1000×2000
|
|
HNF-SR125
|
125
|
950
|
Φ1200×2400
|
650
|
Φ1100×2200
|
|
